Grid & Ribbon Resistors
Crohm Series CG grid and CH high-current resistors are an industry leader for quality construction and dependability, featuring stainless elements and heavy-gauge stainless-steel terminals on double-insulated metal frames. Elements use either offset grids or continuous ribbons, welded for an uninterrupted current path that avoids spacer-related issues. Assemblies use high-temperature silicon-bonded mica insulation for demanding applications.
Applications
- Heavy and medium-duty braking of variable-speed drives
- Neutral grounding applications
- Harmonic filtering
- Motor starting and speed control
- Crane control
- Wound-rotor motor control
- Mining applications
Accessories
- Protective indoor / outdoor enclosures
- Custom engineered assemblies with factory interconnections
- Thermal overload protection
- Medium-voltage enhancements and enclosures
Specifications
| Current ratings | Based on a 375 °C temperature rise |
| Resistance measurement | At 25 °C ambient |
| Standard tolerance | ± 10% (customization available) |
